The Jabsco Ballast Puppy Pump Ballast System seems to be a favorite topic recently, both in the forums, as well as for our ballast experts in the phone, so we figured it could be good for compose a full guide on the best way to design a ballast system around a reversible impeller design ballast pump. As usual, you will find numerous techniques to achieve exactly the same goals, so this shouldn’t be used once the definitive guide on ballast system installations, but instead a recommendation about how to put in a completely practical system that operates properly centered on our years of experience. Go ahead and deviate from all of these programs in which you see fit, or e mail us in the event that you any questions.

With this off the beaten track, let’s proceed to the great things!

Wakeboard Boat Ballast System Basics:

Impeller style pumps (like Jabsco’s Ballast Puppy) tend to be special simply because they can push liquid in both directions, and that means you can use one pump to both fill and strain similar ballast bag(s). Furthermore, impeller type pumps become a check device if not working, preventing the circulation of water into or out from the bag which simplifies the design of this system.

Design and Layout:

Generally speaking, all ballast systems that make usage of reversible pumps will have the next axioms in keeping, although the particulars can vary greatly from a single set up to some other with regards to the appropriate targets or limitations. The system design we’ve outlined in this specific article does use one check device fitting that allows water becoming moved out from the bag when draining to leave the vessel above the water-line. This might be a favorite choice for people as it leads to a visual and audible indication of when the case is draining, when it is bare. Instead, removing the check device, wye installing and affixed thru-hull vent will result in a less complicated and cheaper system that fills and drains through the thru-hull intake fitting.

Wakeboard Ballast Thru-Hull Fittings:
Regardless of the particulars associated with the system, you will have to discover a supply of natural water to make use of to fill. This is often a separate intake fitting put in designed for the ballast system, or can make use of an existing strain connect suitable within the bilge making use of our readily available brass integration accessories. We USUALLY DO NOT suggest making use of the engine’s natural intake of water since the supply of water for the ballast system. The possibility of injury to the engine is certainly not well worth the little amount of convenience throughout the installation.
Shop For Ballast Consumption Areas»

Wakeboard Ballast Pump:
This technique makes use of a reversible impeller type pump produced by Jabsco. Their Ballast Puppy pumps are extremely well-known in this industry, being used by Mastercraft, Nautique, Supra, Moomba, Centurion yet others within their factory ballast system.

Ballast System Plumbing
The particulars of your set up depends on your particular vessel, although basics outlined here are general regardless of vessel.
Soon after the thru-hull intake fitted install a metal ball-valve as a crisis shut-off point out permit you to straight away stop the movement of liquid to the boat if one thing goes wrong.
If you choose to apply something that drains over the water line, next install a check device suitable to prevent liquid from draining right back through intake.
Next is Wye installing to reroute the movement of liquid out of the thru-hull vent installing when draining.
Then comes the pump, and lastly you are able to your connection to the case. Because reversible pumps fill and drain through same case link, you merely need two contacts to your bag, one for completing and draining, and another for ventilation. We recommend using Fly High’s Flow-Rite fast launch Connector system for many bag contacts in order to quickly get rid of the Ballast Puppy pumps Fly High Ballast Bags for cleansing, winterization or storage.

Both the strain and vent hoses are terminated with thru-hull vent fixtures that match the factory design.
